1.7 SATA Interfaces
The board provides four SATA connectors through the PCH, which support one device
per connector:
• Two internal SATA 3.0 Gb/s connectors (black)
• One internal mSATA 3.0 Gb/s port (PCI Express Full-/Half-Mini Card slot)
• One eSATA 3.0 Gb/s connector on the back panel for external connectivity (red)
The PCH provides independent SATA ports with a theoretical maximum transfer rate of
3 Gb/s. A point-to-point interface is used for host to device connections.
The underlying SATA functionality is transparent to the operating system. The SATA
controller can operate in both legacy and native modes. In legacy mode, standard IDE
I/O and IRQ resources are assigned (IRQ 14 and 15). In Native mode, standard PCI
Conventional bus resource steering is used. Native mode is the preferred mode for
configurations using Windows operating systems.
The board has an internal SATA power connector and ships with a power cable for
powering internal SATA storage devices. The power cable includes:
• Right-angled 15-pin SATA female connector (for motherboard connectivity)
• 1 x 4 Molex female connector (for slim optical drive adapter connectivity)
• 15-pin SATA female connector (for storage connectivity)
• Vertical 15-pin SATA female connector (for storage connectivity)
NOTE
Board power supplied through SATA power connector is rated at a maximum of:
• 1.0 A from 12 V rail
• 2.5 A from 5 V rail
• 0.5 A from 3.3 V rail
For information about Refer to
The location of the SATA connectors Figure 13, page 49
1.7.1 AHCI Mode
The board supports AHCI storage mode via the Intel H61 Express Chipset.
NOTE
In order to use AHCI mode, AHCI must be enabled in the BIOS. Also, during Microsoft
Windows XP installation, F6 must be pressed to install the AHCI drivers. See your
Microsoft Windows XP documentation for more information about installing drivers
during installation. Microsoft Windows 7 includes the necessary AHCI drivers without
the need to install separate AHCI drivers during the operating system installation
process, however, it is always good practice to update the AHCI drivers to the latest
available by Intel.

Intel DH61AG Specifications

General

ECC	No
Non-ECC	Yes
Memory channels	Dual-channel
Number of memory slots	2
Supported memory types	DDR3-SDRAM
Maximum internal memory	16.6 GB
Supported memory clock speeds	800, 1066, 1333 MHz
Product family	Desktop board
Product series	Intel desktop board with Intel H61 Express
Processor socket	LGA 1155 (Socket H2)
Product codename	-
Processor manufacturer	Intel
Compatible processor series	Intel Core i3, Intel Core i5, Intel Core i7
Maximum internal memory supported by processor	16 GB
USB 2.0 connectors	3
S/PDIF out connector	1
Number of Parallel ATA connectors	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Component for	Nettop
Market segment	Desktop
Power source type	ATX
Motherboard chipset	Intel® H61
Audio output channels	7.1 channels
Motherboard form factor	mini ITX
Supported storage drive interfaces	SATA II
Parallel processing technology support	Not supported
PCI Express slots version	2.0
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 55 °C
LAN controller	Intel® 82579V
Networking features	10/100/1000 Mbit/sec
Ethernet interface type	Gigabit Ethernet
BIOS type	EFI
ACPI version	3.0b
BIOS memory size	32 Mbit
Status	Discontinued
Form factor	Thin Mini-ITX
Last change	63903513
Born on date	Q2'11
Product name	Intel Desktop Board DH61AG
USB ports quantity	12
Sustainability certificates	ENERGY STAR
Supported RAID configuration	N/A
Audio channels	8.2
Graphics output	LVDS eDP HDMI DVI-I
Motherboard ARK ID	54875
Discrete graphics card model	None
Export Control Classification Number (ECCN)	5A992C
Commodity Classification Automated Tracking System (CCATS)	G400445
Harmonized System (HS) code	8473301180

Weight and Dimensions

Width	172 mm
