Intel DH61AG User Manual

iii
Board Identification Information
Basic Desktop Board DH61AG Identification Information
AA Revision BIOS Revision Notes
G23736-400 AGH6110H.86A.0023 1,2
G23736-500 AGH6110H.86A.0023 1,2
G23736-502 AGH6110H.86A.0023 1,2
Notes:
1. The AA number is found on a small label on the component side of the board.
2. The H61 processor used on this AA revision consists of the following component:
Device Stepping S-Spec Numbers
BD82H61 B3 SLJ4B
Specification Changes or Clarifications
Table 1 indicates the Specification Changes or Specification Clarifications that apply to
the Intel
®
Desktop Board DH61AG.
Table 1. Specification Changes or Clarifications
Date Type of Change Description of Changes or Clarifications
July 2011 Spec Clarification
• The BIOS was updated to AGH6110H.86A.0023 just prior
to product launch.
• Section 2.2.3.3 Power Supply Connectors – additional
i
nformation has been added to the External Power Supply
section.
• Sections 1.10 Audio Subsystem and Section 2.2.3.1 Signal
Tables for the Connectors and Headers have been updated
t
o show that AA revision G23736-400 supports 5.1 analog
surround audio and AA revision G23736-500 supports
both 5.1 and 7.1 analog surround audio.
July 2011 Spec Clarification
• AGH6110H.86A.0027 will not be implemented with AA
Revision G23736-500 as planned. The BIOS will remain at
AGH6110H.86A.0023.
October 2011 Spec Clarification
• Updates were made to Tables 3, 4, and 14.
• References to 2.6A USB current specifics were removed
from the TPS
January Spec Clarification
• Updated Table 26 on page 55 to change the pinout of the
3-wi
re fan.
• Added a Note to Table 31 on page 57 concerning LVDS
single-channel output.
• Added Section 3.8 Hard Disk Drive Password Security
Feature on page 83.

Intel DH61AG Specifications

General

ECC	No
Non-ECC	Yes
Memory channels	Dual-channel
Number of memory slots	2
Supported memory types	DDR3-SDRAM
Maximum internal memory	16.6 GB
Supported memory clock speeds	800, 1066, 1333 MHz
Product family	Desktop board
Product series	Intel desktop board with Intel H61 Express
Processor socket	LGA 1155 (Socket H2)
Product codename	-
Processor manufacturer	Intel
Compatible processor series	Intel Core i3, Intel Core i5, Intel Core i7
Maximum internal memory supported by processor	16 GB
USB 2.0 connectors	3
S/PDIF out connector	1
Number of Parallel ATA connectors	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Component for	Nettop
Market segment	Desktop
Power source type	ATX
Motherboard chipset	Intel® H61
Audio output channels	7.1 channels
Motherboard form factor	mini ITX
Supported storage drive interfaces	SATA II
Parallel processing technology support	Not supported
PCI Express slots version	2.0
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 55 °C
LAN controller	Intel® 82579V
Networking features	10/100/1000 Mbit/sec
Ethernet interface type	Gigabit Ethernet
BIOS type	EFI
ACPI version	3.0b
BIOS memory size	32 Mbit
Status	Discontinued
Form factor	Thin Mini-ITX
Last change	63903513
Born on date	Q2'11
Product name	Intel Desktop Board DH61AG
USB ports quantity	12
Sustainability certificates	ENERGY STAR
Supported RAID configuration	N/A
Audio channels	8.2
Graphics output	LVDS eDP HDMI DVI-I
Motherboard ARK ID	54875
Discrete graphics card model	None
Export Control Classification Number (ECCN)	5A992C
Commodity Classification Automated Tracking System (CCATS)	G400445
Harmonized System (HS) code	8473301180

Weight and Dimensions

Width	172 mm
