Intel DH61AG User Manual

13
1 Product Description
1.1 Overview
1.1.1 Feature Summary
Table 2 summarizes the major features of the board.
Table 2. Feature Summary
Form Factor
Mini-ITX (6.7 inches by 6.7 inches [170.18 millimeters by 170.18 millimeters])
Processor
• Intel
®
Core i7, Intel
®
Core™ i5, Intel
®
Core™ i3, Intel
®
Pentium
®
, Intel
®
Celeron
®
, and Intel
®
Xeon
®
processors in an LGA1155 socket with up to 65 W
TDP:
― Integrated graphics processing (processors with Intel
®
Graphics
Technology)
― Integrated PCI Express* v2.0 interface controller
― Integrated memory controller
Memory
• Two 204-pin DDR3 SDRAM Small Outline Dual Inline Memory Module
(SO-DIMM) sockets
• Support for DDR3 1333 MHz and DDR3 1066 MHz SO-DIMMs
• Support for 1 Gb, 2 Gb, and 4 Gb memory technology
• Support for up to 16 GB of system memory with two SO-DIMMs using 4 Gb
memory technology
• Support for non-ECC memory
• Support for 1.35 V low voltage JEDEC memory
Chipset
Intel
®
H61 Express Chipset consisting of the Intel
®
H61 Express Platform
Controller Hub (PCH)
Graphics
• Integrated graphics support for processors with Intel Graphics Technology:
― High Definition Multimedia Interface* (HDMI*)
― DVI-I
― Internal flat panel displays:
 LVDS
 eDP (Embedded DisplayPort*)
Audio
• 10-channel (8+2) Intel
®
High Definition (Intel
®
HD) audio via the Realtek*
ALC892 audio codec
― Digital/analog stereo line-out (2-in-1 digital/analog back panel jack)
― In-chassis stereo speakers support (3 W/4 Ω via internal header)
― AV-compliant 7.1 (see note on page 32) surround support (analog line-level
via internal header)
― Secondary S/PDIF digital audio output (internal header)
― DMIC digital microphone input (internal header)
― Analo
g line-in (back panel jack)
― Front panel HD Audio/AC’97 headphones/mic support (internal header)
• 8-channel (7.1) Intel High Definition Audio via the HDMI interface
continued

Intel DH61AG Specifications

General

ECC	No
Non-ECC	Yes
Memory channels	Dual-channel
Number of memory slots	2
Supported memory types	DDR3-SDRAM
Maximum internal memory	16.6 GB
Supported memory clock speeds	800, 1066, 1333 MHz
Product family	Desktop board
Product series	Intel desktop board with Intel H61 Express
Processor socket	LGA 1155 (Socket H2)
Product codename	-
Processor manufacturer	Intel
Compatible processor series	Intel Core i3, Intel Core i5, Intel Core i7
Maximum internal memory supported by processor	16 GB
USB 2.0 connectors	3
S/PDIF out connector	1
Number of Parallel ATA connectors	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Component for	Nettop
Market segment	Desktop
Power source type	ATX
Motherboard chipset	Intel® H61
Audio output channels	7.1 channels
Motherboard form factor	mini ITX
Supported storage drive interfaces	SATA II
Parallel processing technology support	Not supported
PCI Express slots version	2.0
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 55 °C
LAN controller	Intel® 82579V
Networking features	10/100/1000 Mbit/sec
Ethernet interface type	Gigabit Ethernet
BIOS type	EFI
ACPI version	3.0b
BIOS memory size	32 Mbit
Status	Discontinued
Form factor	Thin Mini-ITX
Last change	63903513
Born on date	Q2'11
Product name	Intel Desktop Board DH61AG
USB ports quantity	12
Sustainability certificates	ENERGY STAR
Supported RAID configuration	N/A
Audio channels	8.2
Graphics output	LVDS eDP HDMI DVI-I
Motherboard ARK ID	54875
Discrete graphics card model	None
Export Control Classification Number (ECCN)	5A992C
Commodity Classification Automated Tracking System (CCATS)	G400445
Harmonized System (HS) code	8473301180

Weight and Dimensions

Width	172 mm
