Intel DH61AG - Internal S;PDIF or DMIC Header; Single-Port USB 2.0 Header

Intel Desktop Board DH61AG Technical Product Specification
54
Table 21. Internal S/PDIF or DMIC Header
Pin Signal Name Description
1 +3.3 V 3.3 V power (for DMIC module)
2 DMIC_DATA DMIC data signal
3 GND Ground
4 SPDIF_OUT/DMIC_CLK Multiplexed DMIC clock or S/PDIF signal
5 Key (no pin) Key (no pin)
6 +5 V 5 V power (for optical/TOSLINK module)
Table 22. Dual-Port Front Panel USB 2.0 Headers
Pin Signal Name Pin Signal Name
1 +5 V DC 2 +5 V DC
3 D− 4 D−
5 D+ 6 D+
7 Ground 8 Ground
9 KEY (no pin) 10 No Connect
Table 23. Single-Port USB 2.0 Header
Pin Signal Name
1 +5 V DC
2 D−
3 D+
4 Ground
5 Key (no pin)
Table 24. SATA Connectors
Pin Signal Name
1 Ground
2 TXP
3 TXN
4 Ground
5 RXN
6 RXP
7 Ground
