Intel Desktop Board DH61AG Technical Product Specification
20
1.4 System Memory
The board has two 204-pin SO-DIMM sockets and supports the following memory
features:
• 1.5 V DDR3 SDRAM SO-DIMMs with gold plated contacts.
• Support for 1.35 V Low Voltage DDR3 (new JEDEC specification)
• Two independent memory channels with interleaved mode support
• Unbuffered, single-sided or double-sided SO-DIMMs
• 16 GB maximum total system memory (with 4 Gb memory technology). Refer to
Section 2.1.1 on page 45 for information on the total amount of addressable
memory.
• Minimum recommended total system memory: 1024 MB
• Non-ECC SO
-DIMMs
• Serial Presence Detect
• XMP profile support for voltage detection
• DDR3 1333 MHz and DDR3 1066 MHz SDRAM SO-DIMMs
NOTE
To be fully compliant with all applicable DDR SDRAM memory specifications, the board
should be populated with SO-DIMMs that support the Serial Presence Detect (SPD)
data structure. This allows the BIOS to read the SPD data and program the chipset to
accurately configure memory settings for optimum performance. If non-SPD memory
is installed, the BIOS will attempt to correctly configure the memory settings, but
performance and reliability may be impacted or the SO-DIMMs may not function under
the determined frequency.
Table 5 lists the supported SO-DIMM configurations.
Table 5. Supported Memory Configurations
Raw Card
Version
SO-DIMM
Capacity
DRAM Device
Technology
DRAM
Organization
# of DRAM
Devices
A
1 GB 1 Gb 64 M x 16 8
2 GB 2 Gb 128 M x 16 8
B
1 GB 1 Gb 128 M x 8 8
2 GB 2 Gb 256 M x 8 8
C
512 MB 1 Gb 64 M x 16 4
1 GB 2 Gb 128 M x 16 4
F
2 GB 1 Gb 128 M x 8 16
4 GB 2 Gb 256 M x 8 16
8 GB 4 Gb 512 M x 8 16
Note: System memory configurations are based on availability and are subject to change.

Intel DH61AG Specifications

General

ECC	No
Non-ECC	Yes
Memory channels	Dual-channel
Number of memory slots	2
Supported memory types	DDR3-SDRAM
Maximum internal memory	16.6 GB
Supported memory clock speeds	800, 1066, 1333 MHz
Product family	Desktop board
Product series	Intel desktop board with Intel H61 Express
Processor socket	LGA 1155 (Socket H2)
Product codename	-
Processor manufacturer	Intel
Compatible processor series	Intel Core i3, Intel Core i5, Intel Core i7
Maximum internal memory supported by processor	16 GB
USB 2.0 connectors	3
S/PDIF out connector	1
Number of Parallel ATA connectors	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Component for	Nettop
Market segment	Desktop
Power source type	ATX
Motherboard chipset	Intel® H61
Audio output channels	7.1 channels
Motherboard form factor	mini ITX
Supported storage drive interfaces	SATA II
Parallel processing technology support	Not supported
PCI Express slots version	2.0
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 55 °C
LAN controller	Intel® 82579V
Networking features	10/100/1000 Mbit/sec
Ethernet interface type	Gigabit Ethernet
BIOS type	EFI
ACPI version	3.0b
BIOS memory size	32 Mbit
Status	Discontinued
Form factor	Thin Mini-ITX
Last change	63903513
Born on date	Q2'11
Product name	Intel Desktop Board DH61AG
USB ports quantity	12
Sustainability certificates	ENERGY STAR
Supported RAID configuration	N/A
Audio channels	8.2
Graphics output	LVDS eDP HDMI DVI-I
Motherboard ARK ID	54875
Discrete graphics card model	None
Export Control Classification Number (ECCN)	5A992C
Commodity Classification Automated Tracking System (CCATS)	G400445
Harmonized System (HS) code	8473301180

Weight and Dimensions

Width	172 mm
