Intel DH61AG User Manual

Technical Reference
53
Table 18. Analog Surround Audio Header for AA Revision G23736-400
Pin Signal Name Description Pin Signal Name Description
1 Front_L Front left 2 A_GND Analog ground
3 A_GND Analog ground 4 Front_R Front right
5 NC RESERVED 6 A_GND Analog ground
7 A_GND Analog ground 8 NC RESERVED
9 Surr_Rear_L 5.1 surround rear left 10 A_GND Analog ground
11 A_GND Analog ground 12 Surr_Rear_R 5.1 surround rear right
13 Center Center channel 14 A_GND Analog ground
15 A_GND Analog ground 16 LFE Subwoofer/LFE
17 KEY No pin 18 SENSE Dongle detection signal
Table 19. Analog Surround Audio Header for AA Revision G23736-500
Pin Signal Name Description Pin Signal Name Description
1 Front_L Front left 2 A_GND Analog ground
3 A_GND Analog ground 4 Front_R Front right
5 Surr_Side_L 7.1 surround side left 6 A_GND Analog ground
7 A_GND Analog ground 8 Surr_Side_R 7.1 surround side right
9 Surr_Rear_L 5.1/7.1 surround rear
left
10 A_GND Analog ground
11 A_GND Analog ground 12 Surr_Rear_R 5.1/7.1 surround rear
right
13 Center Center channel 14 A_GND Analog ground
15 A_GND Analog ground 16 LFE Subwoofer/LFE
17 KEY No pin 18 SENSE Dongle detection signal
Table 20. Internal Stereo Speakers Header
Pin Signal Name Description
1 Front_L− Analog front left (differential negative)
2 Front_L+ Analog front left (differential positive)
3 Front_R+ Analog front right (differential positive)
4 Front_R− Analog front right (differential negative)

Intel DH61AG Specifications

General

ECC	No
Non-ECC	Yes
Memory channels	Dual-channel
Number of memory slots	2
Supported memory types	DDR3-SDRAM
Maximum internal memory	16.6 GB
Supported memory clock speeds	800, 1066, 1333 MHz
Product family	Desktop board
Product series	Intel desktop board with Intel H61 Express
Processor socket	LGA 1155 (Socket H2)
Product codename	-
Processor manufacturer	Intel
Compatible processor series	Intel Core i3, Intel Core i5, Intel Core i7
Maximum internal memory supported by processor	16 GB
USB 2.0 connectors	3
S/PDIF out connector	1
Number of Parallel ATA connectors	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Component for	Nettop
Market segment	Desktop
Power source type	ATX
Motherboard chipset	Intel® H61
Audio output channels	7.1 channels
Motherboard form factor	mini ITX
Supported storage drive interfaces	SATA II
Parallel processing technology support	Not supported
PCI Express slots version	2.0
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 55 °C
LAN controller	Intel® 82579V
Networking features	10/100/1000 Mbit/sec
Ethernet interface type	Gigabit Ethernet
BIOS type	EFI
ACPI version	3.0b
BIOS memory size	32 Mbit
Status	Discontinued
Form factor	Thin Mini-ITX
Last change	63903513
Born on date	Q2'11
Product name	Intel Desktop Board DH61AG
USB ports quantity	12
Sustainability certificates	ENERGY STAR
Supported RAID configuration	N/A
Audio channels	8.2
Graphics output	LVDS eDP HDMI DVI-I
Motherboard ARK ID	54875
Discrete graphics card model	None
Export Control Classification Number (ECCN)	5A992C
Commodity Classification Automated Tracking System (CCATS)	G400445
Harmonized System (HS) code	8473301180

Weight and Dimensions

Width	172 mm
