Intel Desktop Board DH61AG Technical Product Specification
32
1.10 Audio Subsystem
The board supports Intel HD Audio via the Realtek ALC892 audio codec. The audio
subsystem supports the following features:
• Digital/analog stereo line-out (2-in-1 optical/analog back panel jack)
• In-chassis stereo speakers support (3 W/4 Ω via internal header)
• AV-compliant 7.1 surround (see note below) support (analog line-level via internal
header)
• Analog line-in (back panel jack)
• Signal-to-noise ratios (SNR) of 97 dB for the DACs and 90 dB for the ADCs
• Support for 44.1 kHz/48 kHz/96 kHz/192 kHz sample rates on all analog inputs
and outputs
• Secondary S/PDIF digital audio output (internal header)
• Support for 32 kHz/44.1 kHz/48 kHz/88.2 kHz/96 kHz/192 kHz sample rates at
16-bit/20-bit/24-bit resolution on SPDIF outputs
• DMIC interface (internal header), with support for mono and stereo digital
microphones
• Front panel HD Audio/AC’97 headphones/microphone support (internal header)
• Advanced jack sense for the back panel line-out jack that enables the audio codec
to recognize the connected device
• Microphone input jack that supports a single dynamic, condenser, or electret
microphone
• Windows 7 Ultimate certification
NOTE
• AA revision G23736-400 supports up to 5.1 analog surround audio.
• AA revision G23736-500 supports both 5.1 and 7.1 analog surround audio.
Table 8 lists the supported functions of the front panel and back panel audio jacks.
Table 8. Audio Jack Support
Audio Jack Microphone Headphones Line Out Line In
FP Green Jack Default
FP Pink Jack Default
Rear Green Jack Jack detect
Rear Pink Jack Default
Internal Stereo Speaker Default
Analog Surround Default

Intel DH61AG Specifications

General

ECC	No
Non-ECC	Yes
Memory channels	Dual-channel
Number of memory slots	2
Supported memory types	DDR3-SDRAM
Maximum internal memory	16.6 GB
Supported memory clock speeds	800, 1066, 1333 MHz
Product family	Desktop board
Product series	Intel desktop board with Intel H61 Express
Processor socket	LGA 1155 (Socket H2)
Product codename	-
Processor manufacturer	Intel
Compatible processor series	Intel Core i3, Intel Core i5, Intel Core i7
Maximum internal memory supported by processor	16 GB
USB 2.0 connectors	3
S/PDIF out connector	1
Number of Parallel ATA connectors	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Component for	Nettop
Market segment	Desktop
Power source type	ATX
Motherboard chipset	Intel® H61
Audio output channels	7.1 channels
Motherboard form factor	mini ITX
Supported storage drive interfaces	SATA II
Parallel processing technology support	Not supported
PCI Express slots version	2.0
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 55 °C
LAN controller	Intel® 82579V
Networking features	10/100/1000 Mbit/sec
Ethernet interface type	Gigabit Ethernet
BIOS type	EFI
ACPI version	3.0b
BIOS memory size	32 Mbit
Status	Discontinued
Form factor	Thin Mini-ITX
Last change	63903513
Born on date	Q2'11
Product name	Intel Desktop Board DH61AG
USB ports quantity	12
Sustainability certificates	ENERGY STAR
Supported RAID configuration	N/A
Audio channels	8.2
Graphics output	LVDS eDP HDMI DVI-I
Motherboard ARK ID	54875
Discrete graphics card model	None
Export Control Classification Number (ECCN)	5A992C
Commodity Classification Automated Tracking System (CCATS)	G400445
Harmonized System (HS) code	8473301180

Weight and Dimensions

Width	172 mm
