Intel Desktop Board DH61AG Technical Product Specification
82
3.7 Boot Options
In the BIOS Setup program, the user can choose to boot from a hard drive, optical
drive, removable drive, or the network. The default setting is for the optical drive to
be the first boot device, the hard drive second, removable drive third, and the network
fourth.
3.7.1 Optical Drive Boot
Booting from the optical drive is supported in compliance to the El Torito bootable
CD-ROM format specification. Under the Boot menu in the BIOS Setup program, the
optical drive is listed as a boot device. Boot devices are defined in priority order.
Accordingly, if there is not a bootable CD in the optical drive, the system will attempt
to boot from the next defined drive.
3.7.2 Network Boot
The network can be selected as a boot device. This selection allows booting from the
onboard LAN or a network add-in card with a remote boot ROM installed.
Pressing the <F12> key during POST automatically forces booting from the LAN. To
use this key during POST, the User Access Level in the BIOS Setup program's Security
menu must be set to Full.
3.7.3 Booting Without Attached Devices
For use in embedded applications, the BIOS has been designed so that after passing
the POST, the operating system loader is invoked even if the following devices are not
present:
• Video adapter
• Keyboard
• Mouse
3.7.4 Changing the Default Boot Device During POST
Pressing the <F10> key during POST causes a boot device menu to be displayed. This
menu displays the list of available boot devices. Table 48 lists the boot device menu
options.
Table 48. Boot Device Menu Options
Boot Device Menu Function Keys Description
<↑> or <↓>
Selects a default boot device
<Enter> Exits the menu, and boots from the selected device
<Esc> Exits the menu and boots according to the boot priority
defined through BIOS setup

Intel DH61AG Specifications

General

ECC	No
Non-ECC	Yes
Memory channels	Dual-channel
Number of memory slots	2
Supported memory types	DDR3-SDRAM
Maximum internal memory	16.6 GB
Supported memory clock speeds	800, 1066, 1333 MHz
Product family	Desktop board
Product series	Intel desktop board with Intel H61 Express
Processor socket	LGA 1155 (Socket H2)
Product codename	-
Processor manufacturer	Intel
Compatible processor series	Intel Core i3, Intel Core i5, Intel Core i7
Maximum internal memory supported by processor	16 GB
USB 2.0 connectors	3
S/PDIF out connector	1
Number of Parallel ATA connectors	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Component for	Nettop
Market segment	Desktop
Power source type	ATX
Motherboard chipset	Intel® H61
Audio output channels	7.1 channels
Motherboard form factor	mini ITX
Supported storage drive interfaces	SATA II
Parallel processing technology support	Not supported
PCI Express slots version	2.0
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 55 °C
LAN controller	Intel® 82579V
Networking features	10/100/1000 Mbit/sec
Ethernet interface type	Gigabit Ethernet
BIOS type	EFI
ACPI version	3.0b
BIOS memory size	32 Mbit
Status	Discontinued
Form factor	Thin Mini-ITX
Last change	63903513
Born on date	Q2'11
Product name	Intel Desktop Board DH61AG
USB ports quantity	12
Sustainability certificates	ENERGY STAR
Supported RAID configuration	N/A
Audio channels	8.2
Graphics output	LVDS eDP HDMI DVI-I
Motherboard ARK ID	54875
Discrete graphics card model	None
Export Control Classification Number (ECCN)	5A992C
Commodity Classification Automated Tracking System (CCATS)	G400445
Harmonized System (HS) code	8473301180

Weight and Dimensions

Width	172 mm
