Product Description
23
1.5 Intel
®
H61 Express Chipset
Intel H61 Express Chipset with Direct Media Interface (DMI) interconnect provides
interfaces to the processor and the USB, SATA, LPC, LAN, and PCI Express interfaces.
The Intel H61 Express Chipset is a centralized controller for the board’s I/O paths.
For information about Refer to
The Intel H61 chipset http://www.intel.com/products/desktop/chipsets/index.htm
Resources used by the chipset Chapter 2
1.6 Graphics Subsystem
The board supports graphics through Intel Graphics Technology.
1.6.1 Integrated Graphics
The board supports integrated graphics through the Intel
®
Flexible Display Interface
(Intel
®
FDI) for processors with Intel Graphics Technology.
NOTE
If using a processor with integrated graphics, the board can simultaneously support up
to two of the three integrated graphics interfaces: HDMI, DVI-I, and Flat Panel
Display.
Flat Panel Display is supported by eDP and LVDS interfaces, however only one can be
used at a time.
1.6.1.1 Intel
®
High Definition (Intel
®
HD) Graphics
The Intel HD graphics controller features the following:
• 3D Features
⎯ DirectX* 10.1 and OpenGL* 3.0 compliant
⎯ DirectX 11.0 CS4.0 only
⎯ Shader Model 4.0
• Video
⎯ Hi-Definition content at up to 1080p resolution
⎯ Hardware accelerated MPEG-2, VC-1/WMV and H.264/AVC Hi-Definition video
formats
⎯ Intel
®
HD Technology with Advanced Hardware Video Transcoding
⎯ Blu-ray* S3D via HDMI 1.4
⎯ Dynamic Video Memory Technology (DVMT) 5.0 support
⎯ Support of up to 1.7 GB Video Memory with 4 GB and above system memory
configuration
