Intel DH61AG User Manual

Technical Reference
47
2.1.2 Memory Map
Table 13 lists the system memory map.
Table 13. System Memory Map
Address Range (decimal) Address Range (hex) Size Description
1024 K - 16777216 K 100000 – 400000000 16382 MB Extended memory
960 K - 1024 K F0000 - FFFFF 64 KB Runtime BIOS
896 K - 960 K E0000 - EFFFF 64 KB Reserved
800 K - 896 K C8000 - DFFFF 96 KB Potential available high DOS
memory (open to the PCI
Conventional bus). Dependent on
video adapter used.
640 K - 800 K A0000 - C7FFF 160 KB Video memory and BIOS
639 K - 640 K 9FC00 - 9FFFF 1 KB Extended BIOS data (movable by
memory manager software)
512 K - 639 K 80000 - 9FBFF 127 KB Extended conventional memory
0 K - 512 K 00000 - 7FFFF 512 KB Conventional memory
2.2 Connectors and Headers
CAUTION
Only the following connectors and headers have overcurrent protection: back panel
and front panel USB.
The other internal connectors and headers are not overcurrent protected and should
connect only to devices inside the computer’s chassis, such as fans and internal
peripherals. Do not use these connectors or headers to power devices external to the
computer’s chassis. A fault in the load presented by the external devices could cause
damage to the computer, the power cable, and the external devices themselves.
Furthermore, improper connection of USB header single wire connectors may
eventually overload the overcurrent protection and cause damage to the board.
This section describes the board’s connectors and headers. The connectors and
headers can be divided into these groups:
• Back panel I/O connectors
• On-board I/O connectors and headers (see page 49 and page 51)

Intel DH61AG Specifications

General

ECC	No
Non-ECC	Yes
Memory channels	Dual-channel
Number of memory slots	2
Supported memory types	DDR3-SDRAM
Maximum internal memory	16.6 GB
Supported memory clock speeds	800, 1066, 1333 MHz
Product family	Desktop board
Product series	Intel desktop board with Intel H61 Express
Processor socket	LGA 1155 (Socket H2)
Product codename	-
Processor manufacturer	Intel
Compatible processor series	Intel Core i3, Intel Core i5, Intel Core i7
Maximum internal memory supported by processor	16 GB
USB 2.0 connectors	3
S/PDIF out connector	1
Number of Parallel ATA connectors	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Component for	Nettop
Market segment	Desktop
Power source type	ATX
Motherboard chipset	Intel® H61
Audio output channels	7.1 channels
Motherboard form factor	mini ITX
Supported storage drive interfaces	SATA II
Parallel processing technology support	Not supported
PCI Express slots version	2.0
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 55 °C
LAN controller	Intel® 82579V
Networking features	10/100/1000 Mbit/sec
Ethernet interface type	Gigabit Ethernet
BIOS type	EFI
ACPI version	3.0b
BIOS memory size	32 Mbit
Status	Discontinued
Form factor	Thin Mini-ITX
Last change	63903513
Born on date	Q2'11
Product name	Intel Desktop Board DH61AG
USB ports quantity	12
Sustainability certificates	ENERGY STAR
Supported RAID configuration	N/A
Audio channels	8.2
Graphics output	LVDS eDP HDMI DVI-I
Motherboard ARK ID	54875
Discrete graphics card model	None
Export Control Classification Number (ECCN)	5A992C
Commodity Classification Automated Tracking System (CCATS)	G400445
Harmonized System (HS) code	8473301180

Weight and Dimensions

Width	172 mm
