Intel Desktop Board DH61AG Technical Product Specification
50
Table 14 lists the connectors and headers identified in Figure 13.
Table 14. Connectors and Headers Shown in Figure 13
Item from
Figure 13 Descript
ion
Connector Information
Board Connector Mating Plug
A Internal stereo speakers header JS*-1125-04 JWT*-A2001H02-4P
B HTPC header 2x4, 2.00mm-pitch
C Internal power connector Molex* 5566-2 Molex 5557-02R
D PCI Express Full-/Half-Mini Card slot
E System fan header 4-wire/3-wire fan
F Single port USB 2.0 header 1x5, 2.54mm-pitch
G SATA data connectors 7-pin SATA (male) 7-pin SATA (female)
H SATA power connector 15-pin SATA (male) 15-pin SATA (female)
I Processor fan header 4-wire fan
J Consumer IR receiver header 2x4, 2.54mm-pitch
K Front panel header 2x5, 2.54mm-pitch
L Flat panel voltage selection header 2x3, 2.54mm-pitch Jumper
M LVDS connector ACES* 88341-40 ACES 88441-40
Starcom* 107F40
N FPD brightness connector Foxconn* HF5508 JWT A2001H02-8P
O Backlight inverter voltage selection header 1x3 2.54mm-pitch Jumper
P Front panel dual-port USB 2.0 header 2x5, 2.54mm-pitch
Q Debug connector 1x11, 1.25mm-pitch
R Front panel dual-port USB 2.0 header 2x5, 2.54mm-pitch
S PCI Express Half-Mini Card slot
T PCI Express 2.0 x4 connector
U Front panel audio header 2x5, 2.54mm-pitch
V Internal S/PDIF / DMIC header 1x6, 2.54mm-pitch
W Analog surround audio header 2x9, 2.00mm-pitch

Intel DH61AG Specifications

General

ECC	No
Non-ECC	Yes
Memory channels	Dual-channel
Number of memory slots	2
Supported memory types	DDR3-SDRAM
Maximum internal memory	16.6 GB
Supported memory clock speeds	800, 1066, 1333 MHz
Product family	Desktop board
Product series	Intel desktop board with Intel H61 Express
Processor socket	LGA 1155 (Socket H2)
Product codename	-
Processor manufacturer	Intel
Compatible processor series	Intel Core i3, Intel Core i5, Intel Core i7
Maximum internal memory supported by processor	16 GB
USB 2.0 connectors	3
S/PDIF out connector	1
Number of Parallel ATA connectors	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Component for	Nettop
Market segment	Desktop
Power source type	ATX
Motherboard chipset	Intel® H61
Audio output channels	7.1 channels
Motherboard form factor	mini ITX
Supported storage drive interfaces	SATA II
Parallel processing technology support	Not supported
PCI Express slots version	2.0
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 55 °C
LAN controller	Intel® 82579V
Networking features	10/100/1000 Mbit/sec
Ethernet interface type	Gigabit Ethernet
BIOS type	EFI
ACPI version	3.0b
BIOS memory size	32 Mbit
Status	Discontinued
Form factor	Thin Mini-ITX
Last change	63903513
Born on date	Q2'11
Product name	Intel Desktop Board DH61AG
USB ports quantity	12
Sustainability certificates	ENERGY STAR
Supported RAID configuration	N/A
Audio channels	8.2
Graphics output	LVDS eDP HDMI DVI-I
Motherboard ARK ID	54875
Discrete graphics card model	None
Export Control Classification Number (ECCN)	5A992C
Commodity Classification Automated Tracking System (CCATS)	G400445
Harmonized System (HS) code	8473301180

Weight and Dimensions

Width	172 mm
