Intel E6700 - Core 2 Duo Dual-Core Processor User Manual

Mechanical Drawings
Thermal and Mechanical Design Guidelines 111
Figure 7-41. ATX/µATX Motherboard Keep-out Footprint Definition and Height Restrictions for Enabling Components - Sheet 2
13
4
5678
B
C
D
A
123
4
5678
B
C
D
A
THIS DRAWING CONTAINS INTEL CORPORAT ION CONFIDENTIAL INFORMATION. IT IS DISCLOSED IN CONFIDENCE AND ITS CONT ENTS
MAY NOT BE DISCLOSED, REPRODUCED, DI SPLAYED OR MODIFIED, WITHOUT THE PRI OR WRITTEN CONSENT OF INTEL CORPORAT ION.
4X
6.00
4X
10.00
LEGEND
COMPONENT KEEP-OUT
ROUTING KEEP-OUT
SHEET 2 OF 3 DO NOT SCALE DRAWING SCALE: NONE
2200 MISSION COLLEGE BLVD.
P.O. BOX 58119
SANTA CLARA, CA 95052-8119
CORP.
R
TMD
3 C40819 D
REVDRAWING NUMBERCAGE CODE SIZE DEPARTMENT
C40819 2 3
DWG. NO SHT. REV
SOCKET BALL 1
COMPONENT VOLUMETRIC
KEEP-INS
ROUTING KEEP-OUTS
SOCKET & PROCESSOR
VOLUMETRIC KEEP-IN OUTLINE
BOARD SECONDARY SIDE
SOCKET BALL 1
(FAR SIDE)
SOCKET & PROCESSOR
VOLUMETRIC KEEP-IN

Intel E6700 - Core 2 Duo Dual-Core Processor Specifications

General

Processor Number	E6700
Number of Cores	2
Number of Threads	2
Base Frequency	2.66 GHz
Cache	4 MB L2 Cache
Bus Speed	1066 MHz
TDP	65 W
Socket	LGA 775
Lithography	65 nm
Instruction Set	64-bit
Virtualization Technology	VT-x
Memory Types	DDR2
Release Date	July 2006
