ATX Thermal/Mechanical Design Information
Thermal and Mechanical Design Guidelines 53
6.2 Validation Results for Reference Design
6.2.1 Heatsink Performance
Table 6–1 provides the E18764-001 heatsink performance for the processors of Intel
Core™2 Duo processor E8000 series with 6 MB cache, Intel Core™2 Duo processor
E7000 series with 3 MB cache, Intel Pentium dual-core processor E6000, E5000 series
with 2 MB cache, and Intel
®
Celeron
®
processor E3000 series with 1 MB cache. The
results are based on the test procedure described in Section 6.2.4.
The tables also include a T
A
assumption of 40 °C for the Intel reference thermal
solution at the processor fan heatsink inlet discussed Section 2.4.1.
Table 6–1. E18764-001 Reference Heatsink Performance
Processor
Target Thermal
Performance,
Ψ
ca
(Mean + 3
σ
)
T
A
Assumption
Notes
Intel Core™2 Duo processor E8000
series with 6 MB cache
0.50 °C/W 40 °C 1, 2
Intel Core™2 Duo processor E7000
series with 3 MB cache / Intel Pentium
dual-core processor E6000, E5000
series with 2 MB cache / Intel
®
Celeron
®
processor E3000 series
0.52 °C/W 40 °C 1, 2
NOTES:
1. Performance targets (Ψ ca) as measured with a live processor at TDP.
2. The difference in Ψ ca between the Intel Core™2 Duo processor E8000 series with
6 MB cache and Intel Core™2 Duo processor E7000 series with 3 MB cache, Intel
Pentium dual-core processor E6000, E5000 series with 2 MB cache, and Intel
®
Celeron
®
processor E3000 series with 1 MB cache is due to a slight difference in the die size.

Intel E6700 - Core 2 Duo Dual-Core Processor Specifications

General

Processor Number	E6700
Number of Cores	2
Number of Threads	2
Base Frequency	2.66 GHz
Cache	4 MB L2 Cache
Bus Speed	1066 MHz
TDP	65 W
Socket	LGA 775
Lithography	65 nm
Instruction Set	64-bit
Virtualization Technology	VT-x
Memory Types	DDR2
Release Date	July 2006
