Introduction
R
Thermal/Mechanical Design Guide 11
1.2 References
Material and concepts available in the following documents may be beneficial when reading this
document.
Document Document Link
Intel
®
Pentium
®
4 Processor 6xx
∆
and Intel
®
Pentium
®
4
Processor Extreme Edition Datasheet – On 90 nm Process in
the 775-land LGA Package, supporting Intel
®
Extended
Memory 64 Technology
Φ
, and supporting Intel
®
Virtualization
Technology.
http://intel.com/design/pentium4/datashts/
306382.htm
Intel
®
Pentium
®
4 Processors 570/571, 560/561, 550/551,
540/541, 530/531, and 520/521
∆
Supporting Hyper-Threading
Technology – On 90 nm Process in the 775–Land LGA
Package and Supporting Intel Extended Memory 64
Technology
Φ
Datasheet
http://developer.intel.com/design/Pentium
4/datashts/302351.htm
LGA775 Socket Mechanical Design Guide http://developer.intel.com/design/Pentium
4/guides/302666.htm
Boxed Intel® Pentium® 4 Processor in the 775-Land LGA
Package - Integration Video
http://www.intel.com/go/integration
Fan Specification for 4-wire PWM Controlled Fans http://www.formfactors.org/
Performance ATX Desktop System Thermal Design
Suggestions
http://www.formfactors.org/
Performance microATX Desktop System Thermal Design
Suggestions
http://www.formfactors.org/
Balanced Technology Extended (BTX) System Design Guide http://www.formfactors.org/
