Intel PENTIUM P6000 - DATASHEET 2010 - Page 168

168 Datasheet
Processor Pin and Signal Information
BE64 SA_DQS[7] DDR3 I/O
BE65 VSS GND
BE69 RSVD
BE70 VSS GND
BE71 RSVD
BF2 SB_DQ[6] DDR3 I/O
BF6 SA_DQ[13] DDR3 I/O
BF8 VSS GND
BF9 SA_DQ[12] DDR3 I/O
BF11 SA_DQ[8] DDR3 I/O
BF13 VSS GND
BF15 VDDQ REF
BF16 VDDQ REF
BF20 SA_CKE[0] DDR3 O
BF21 SA_BS[2] DDR3 O
BF28 SA_MA[9] DDR3 O
BF30 VSS GND
BF38 SA_WE# DDR3 O
BF40 SA_MA[13] DDR3 O
BF43 SA_ODT[0] DDR3 O
BF47 SA_DQ[34] DDR3 I/O
BF48 SA_DQ[35] DDR3 I/O
BF55 SA_DQ[48] DDR3 I/O
BF57 SA_DQ[52] DDR3 I/O
BF59 VTT0 REF
BF60 VTT0 REF
BF62 VSS GND
BF64 SA_DQ[57] DDR3 I/O
BF65 SA_DQ[61] DDR3 I/O
BF67 SB_DM[7] DDR3 O
BF70 SB_DQ[57] DDR3 I/O
BG1 SB_DQ[9] DDR3 I/O
BG4 SB_DQ[8] DDR3 I/O
BG15 SA_DQ[21] DDR3 I/O
BG17 SA_DQ[18] DDR3 I/O
BG24 SA_DQ[30] DDR3 I/O
Table 8-52.BGA1288 Processor Ball
List by Ball Number
(Sheet 19 of 37)
Pin # Pin Name
Buffer
Type
Dir
BG25 SA_DQ[31] DDR3 I/O
BG32 SA_MA[4] DDR3 O
BG34 SA_MA[3] DDR3 O
BG36 VSS GND
BG43 VDDQ REF
BG44 SA_DM[4] DDR3 O
BG51 VSS GND
BG53 SA_DM[5] DDR3 O
BG69 SB_DQS#[7] DDR3 I/O
BG71 SB_DQ[58] DDR3 I/O
BH2 SB_DQ[7] DDR3 I/O
BH13 SA_DQ[11] DDR3 I/O
BH15 VSS GND
BH17 SA_DQ[22] DDR3 I/O
BH20 VSS GND
BH21 SA_DQ[29] DDR3 I/O
BH24 VSS GND
BH25 SA_DQ[27] DDR3 I/O
BH28 VDDQ REF
BH30 SA_MA[11] DDR3 O
BH32 VDDQ REF
BH34 SA_MA[10] DDR3 O
BH36 SA_CK#[1] DDR3 O
BH38 SA_BS[1] DDR3 O
BH40 SA_CS#[0] DDR3 O
BH43 SA_DQ[37] DDR3 I/O
BH44 SA_DQS#[4] DDR3 I/O
BH47 VSS GND
BH48 SA_DQ[44] DDR3 I/O
BH51 SA_DQS[5] DDR3 I/O
BH53 SA_DQ[42] DDR3+
C285
I/O
BH55 VSS GND
BH57 VSS GND
BH59 SA_DM[7] DDR3 I/O
BH70 VSS GND
Table 8-52.BGA1288 Processor Ball
List by Ball Number
(Sheet 20 of 37)
Pin # Pin Name
Buffer
Type
Dir
