Intel PENTIUM P6000 - DATASHEET 2010 - Page 169

Datasheet 169
Processor Pin and Signal Information
BJ1 VSS GND
BJ4 SB_DQ[12] DDR3 I/O
BJ5 SA_DQS[1] DDR3 I/O
BJ7 SA_DQS#[1] DDR3 I/O
BJ9 VSS GND
BJ10 SA_DM[1] DDR3 I/O
BJ12 SM_DRAMRST# DDR3 O
BJ20 SA_DQ[28] DDR3 I/O
BJ21 VSS GND
BJ28 SA_MA[12] DDR3 O
BJ30 SA_MA[7] DDR3 O
BJ38 VDDQ REF
BJ40 SA_DQ[32] DDR3 I/O
BJ47 SA_CS#[1] DDR3 I/O
BJ48 SA_DQ[45] DDR3 I/O
BJ55 SA_DQ[43] DDR3 I/O
BJ57 SA_DQ[53] DDR3 I/O
BJ61 SA_DQ[51] DDR3 I/O
BJ63 SA_DQ[56] DDR3 I/O
BJ64 VSS GND
BJ66 SA_DQ[60] DDR3 I/O
BJ69 SB_DQS[7] DDR3 I/O
BJ71 SB_DQ[56] DDR3 I/O
BK2 SB_DQ[13] DDR3 I/O
BK5 SA_DQ[10] DDR3 I/O
BK7 SA_DQ[14] DDR3 I/O
BK9 SA_DQ[20] DDR3 I/O
BK10 VSS GND
BK15 SA_DQ[19] DDR3 I/O
BK17 SA_DQ[23] DDR3 I/O
BK24 SA_CKE[1] DDR3 O
BK25 SA_DQ[26] DDR3 I/O
BK32 SA_MA[6] DDR3 O
BK34 VSS GND
BK36 SA_CK[1] DDR3 O
BK43 SA_CAS# DDR3 O
Table 8-52.BGA1288 Processor Ball
List by Ball Number
(Sheet 21 of 37)
Pin # Pin Name
Buffer
Type
Dir
BK44 SA_DQS[4] DDR3 I/O
BK51 SA_DQS#[5] DDR3 I/O
BK53 VSS GND
BK60 VSS GND
BK61 SA_DQ[55] DDR3 I/O
BK63 VSS GND
BK64 SA_DQ[54] DDR3 I/O
BK67 SB_DQ[61] DDR3 I/O
BK70 SB_DQ[60] DDR3 I/O
BL1 VSS GND
BL4 SB_DM[1] DDR3 O
BL13 SA_DQS[2] DDR3 I/O
BL20 VSS GND
BL21 SA_DQS#[3] DDR3 I/O
BL28 VSS GND
BL30 VDDQ REF
BL38 SA_RAS# DDR3 O
BL40 VSS GND
BL47 SA_ODT[1] DDR3 O
BL48 VSS GND
BL55 VSS GND
BL57 VSS GND
BL69 SB_DQ[55] DDR3 I/O
BL71 VSS GND
BM3 SB_DQS#[1] DDR3 I/O
BM15 SA_DM[2] DDR3 O
BM17 VSS GND
BM24 VSS GND
BM25 VDDQ REF
BM32 VSS GND
BM34 SA_CK[0] DDR3 O
BM43 SA_DQ[33] DDR3 I/O
BM44 VSS GND
BM51 VSS GND
BM53 SA_DQ[46] DDR3 I/O
BM60 SA_DQS[6] DDR3 I/O
Table 8-52.BGA1288 Processor Ball
List by Ball Number
(Sheet 22 of 37)
Pin # Pin Name
Buffer
Type
Dir
