Intel® Server S2600WF Product Family Configuration Guide
89
Details
Description
iPC
A2U8PSWCXCXK2
MM#
958270
UPC
00735858346252
EAN
5032037106535
MOQ
1
2U 8 port Switch accessory cable kit, Riser 1 or Riser 2 (2 cables included). Contains the following
OCuLink bundled cables:
875 mm long, bundled cable kit (2 cables included) straight OCuLink SFF-8611connectors to
straight/right angle OCuLink SFF-8611 connectors
Used in the R2208+8 and R2224 to connect switch AIC installed in Riser 2 to HSBP PCIe SSD ports
0 -7
iPC
A2U8PSWCXCXK3
MM#
958272
UPC
00735858346269
EAN
5032037106542
MOQ
1
2U 8 port Switch accessory cable kit, Riser 2 (2 cables included). Contains the following OCuLink
bundled cables:
810 mm long, bundled cable kit (2 cables included) straight OCuLink SFF-8611connectors to
straight/right angle OCuLink SFF-8611 connectors
Used in the R2224 to connect switch AIC 2 installed in Riser 2 to HSBP PCIe SSD ports 0 -7
iPC
AXXCBL700HDCV
MM#
958273
UPC
00735858346276
EAN
5032037106559
MOQ
1
700 mm long, cable kit (2 cables included) straight SFF-8643 connector to dual straight OCuLink
SFF-8611 connectors
Used to connect Trimode RAID AICs to HSBP PCIe #0 & PCIe #1 and PCIe #2 & PCIe #3
iPC
A1U4PTRICXCVK
MM#
984361
UPC
00735858393270
EAN
5032037140836
MOQ
1
Cable kit includes:
(1) – 600 mm dual right angle SFF-8643 connector to dual straight OCuLink SFF-8611 connectors
(1) – 700 mm dual right angle SFF-8643 connector to dual straight OCuLink SFF-8611 connectors
Used to connect Trimode RAID AICs to HSBP PCIe #0 & PCIe #1 and PCIe #2 & PCIe #3
Used to connect Trimode RAID AICs to HSBP PCIe #4 & PCIe #5 and PCIe #6 & PCIe #7
