Intel® Server S2600ST Product Family Configuration Guide and Spares/Accessories List
6
Server Board Features
Detail
Server Board SKU
S2600STB
S2600STQ
PCIe* Add-in Card Slots
• Slot 1: PCIe* 3.0 x8 slot (x8 electrical) handled by CPU2
• Slot 2: PCIe* 3.0 x16 slot (x16 electrical) handled by CPU2 (Riser capable)
• Slot 3: PCIe* 3.0 x8 slot (x8 electrical) handled by CPU2
• Slot 4: PCIe* 3.0 x16 slot (x16 electrical) handled by CPU2
• Slot 5: PCIe* 3.0 x8 slot (x8 electrical) handled by CPU1
• Slot 6: PCIe* 3.0 x16 slot (x16 electrical) handled by CPU1 (Riser capable)
Video
•
Integrated 2D Video Controller
• 16MB of DDR4 Video Memory
• One (1) DB-15 External Connector
USB Support
• Two (2) external USB 2.0 Ports
• Two (2) external USB 3.0 Ports
• One (1) internal USB 3.0 type A connector
• One (1) 2x10 pin connector providing front panel support for two USB 2.0 / 3.0 ports
Serial Port Support
• One (1) internal DH-10 Serial Port A connector
Server Management
•
Integrated Baseboard Management Controller, IPMI 2.0 compliant
• Support for Intel
®
Server Management Software
• Dedicated On-board RJ45 management port
• Advanced Server Management via an Intel® Remote Management Module 4 Lite (Accessory
Option)
Security
Intel® Trusted Platform Module 2.0 (Rest of World), iPC- AXXTPMENC8
Intel® Trusted Platform Module 2.0 (China Version), iPC - AXXTPME8
System Fan Support
• Two (2) processor fans through 4-pin headers
• Up to six (6) front system fans through 6-pin headers
• One (1) rear system fan through a 4-pin header
The Intel® Server Board S2600ST product family is compatible with the following Intel® Server Chassis P4000 options:
• iPC – P4304XXMFEN2
• iPC – P4304XXMUXX
Main features are identified in the following illustrations
