Intel® Server S2600ST Product Family Configuration Guide and Spares/Accessories List
29
3.3 Intel® SAS / SATA / OCuLink Cable Kits
Table 21. Storage Data Cable Kit Description and Order Information
Intel Product Code Order Information Product Description
iPC - AXXCBL380HDHD
MM# - 936427
UPC - 00735858284738
EAN - 5032037065023
MOQ - 1
380mm long, cable kit (2 cables included).
Straight Mini-SAS HD (SFF-8643) to straight Mini-SAS HD (SFF-
8643)
Used for connecting Hot Swap drive bays to mainboard SATA
ports.
iPC - AXXCBL450HD7S
MM# - 936428
UPC - 00735858287388
EAN - 5032037067126
MOQ - 1
450mm long, cable kit (2 cables included).
Straight Mini-SAS HD (SFF-8643) to straight 7-pin SATA.
Used to connect fixed SATA drives to mainboard SATA ports.
Spare for cables shipped with chassis.
iPC - AXXCBL650HDHD
MM# - 937129
UPC - 735858284752
EAN - 5032037065047
MOQ - 1
650mm long, cable kit (2 cables included).
Straight Mini-SAS HD (SFF-8643) to straight Mini-SAS HD (SFF-
8643)
Used to connect 12G/s SAS cards (with SFF-8643 connectors) to
backplanes
iPC - AXXCBL900HD7R
MM# - 937316
UPC 735858286640
EAN 5032037066549
MOQ – 1
Cable kit with two 730 mm cables for straight MiniSAS-HD
(SFF8643) to right angle 7-pin connectors
