Intel® Server S2600ST Product Family Configuration Guide and Spares/Accessories List
15
iPC - P4304XXMUXX
Order Code Information:
MM# - 937011
UPC - 00735858289962
EAN - 5032037068802
MOQ - 1
Product Type: Chassis Only
Chassis Form Factor: 4U rack mount
Chassis dimensions: L=612mm, W=173mm,
H=438mm
Packaged Gross Weight: 23.8 Kgs, 52.4 Lbs
Un-packaged Net Weight: 15.5 Kgs, 34.2 Lbs
Outer Box Dimensions: L=813mm,
W=348mm, H=577mm
Product Definition and Configuration Requirements
Intel product code P4304XXMUXX includes the
following components:
(1) – 4U Chassis
(1) - Standard Control Panel – iPC FXXFPANEL
(1) - Power Distribution Board – iPC FUPPDBHC2
(1) – Power Supply Bay – iPC FUPCRPSCAGE
(5) – Redundant/Hot swap 80mm system fans - iPC
FUPMLHSFAN
(4) - Fixed 3.5”/2.5” drive sleds - iPC FUP4X35NHDK
(1) – Processor/Memmory air duct – iPC A4UCWDUCT
(1) – Hot swap bezel with lock – iPC FUPBEZELHSD2
(1) – Fixed EMI cover
(1) - Attention document
(1) – Dual power Connector Cable iPN – G22872-00x
(1) – Mini-SAS HD to 4 ports SATA 7 pins cable –
AXXCBL450HD7S
(1) – Chassis plastic Foot iPN – G35111-00x
(1) – Set of standoffs for Motherboard iPN – G35101-
00x
(1) – Bumper pad for Motherboard iPN – G35112-00x
(1) – Set of 5mm screws for Motherboad iPN – G35096
Required Items – Sold Separately:
• Intel® Server Board S2600ST (choose one)
o iPC S2600STB – with 4 PCIe* OCuLink*
connectors
o iPC S2600STQ – with Intel® Quick Assist
Technology and 2 PCIe* OCuLink*
connectors
• Power Supply
• Power Cord(s)
Note: Chassis shipped to the US & Canada will contain
North American power cords.
• 1 or 2 Intel® Xeon® processor Scalable family
• DDR4 memory (RDIMM or LRDIMM)
• SATA and/or OCuLink cables
Optional Intel Accessories – Sold Separately:
• Hot swap drive bay kit - See Section 4.1 for options
• Intel® SAS RAID Card – See Section 4.3 for options.
• Power supply - See Section 4.4 for options.
• OCulink Data cable – Depending on the location of
the OCulink connector, a new data cable may be
necessary. See Section 3.3
• iPC AXXRMM4LITE2 – Intel® Remote Management
Module Lite key. For advanced management
features
• Storage Drives
See Chapter 4 for all available accessory options.
