Intel® Server S2600ST Product Family Configuration Guide and Spares/Accessories List
19
Each table in the following sections describes the cable connections and lists recommended cable lengths for each supported storage controller
option in the specified system. Each “recommended” cable length for a given connector pair provides enough cable to attach the two devices
with the least amount of excess cable, resulting in the cleanest cable routing. See Table 21. Storage Data Cable Kit Description and Order
Information for appropriate cable kits to use on your system.
3.2.1 Fixed Mount Drive SAS/SATA Data Cable Guide
One Mini-SAS HD cable - iPC AXXCBL450HD7S is included in the server chassis. Additional cables ordered separately as required.
By default the Intel server chassis has support for four fixed mount drives. In order to support 8x2.5” / 8x3.5” fixed drive configurations, an
additional set of drive trays (iPC - FUP4X35NHDK) is needed and must be ordered separately.
Table 12. Fixed Mount Drive Configuration SATA Cable Guide
Cables for On-Board SATA Capable Controller to Storage Drive Cables for 12 Gb SAS RAID PCIe* add-in card to Storage Drive
Fixed 4x3.5” /
Fixed 4x2.5”
450mm HD --- 7S
(1) AXXCBL450HD7S
Cable is included with the server chassis
900mm HD ---
(1) AXXCBL900HD7R
Required – ordered separately:
(1) AXXCBL900HD7R – 900mm HD 7R cable, includes two cables.
Fixed 8x3.5” /
Fixed 8x2.5”
sSATA-> Drive
450mm HD --- 7S
(2) AXXCBL450HD7S – One cable included in chassis. Second cable ordered
separately.
Required – ordered separately:
(1) AXXCBL450HD7S – 450mm HD 7S cable, includes two cables.
(2) FXXSTPWRAD – Power adapter cable kit. Two drives supported per kit.
900mm HD --- 7S
(2) AXXCBL900HD7S – One cable included in chassis. Second cable ordered
separately.
Required – ordered separately:
(2) AXXCBL450HD7S – 450mm HD 7S cable, includes two cables.
(2) FXXSTPWRAD – Power adapter cable kit. Two drives supported per kit.
