Intel® Server S2600ST Product Family Configuration Guide and Spares/Accessories List
23
Table 15. Combo Backplane Module Placement – 8 x 2.5” front drive configurations
Drive Support
Cables for On-Board SATA
Controller to Backplane
Cables for 12 Gb SAS RAID PCIe*
add-in card to Backplane
Cables for Onboard
SAS/SATA/PCIe OCuLink to
backplane
Cables for PCIe NVME AIC to
Backplane OCuLink
Hot-swap 8x2.5”
Combo
SAS / SATA / PCIe*
SSD SFF (NVMe)
12 Gb SAS capable
On-Board SATA -> BP
380mm HD --- HD
(2) AXXCBL380HDHD
The kit includes two cables.
SAS Add-in card -> BP
650mm HD --- HD
(2) AXXCBL650HDHD
The kit includes two cables.
On-board PCIe SSD 1 -> BP0
On-board PCIe SSD 2 -> BP1
On-board PCIe SSD 3 -> BP2
On-board PCIe SSD 4 -> BP3
(1) AXXCBL450CVCR
The Kit includes one 450 mm
bundled cable.
On-Board SATA -> BP 4-7
380mm HD --- HD
(1) AXXCBL380HDHD
The kit includes two cables.
4P Switch AIC -> BP 0-3
(1) AXXCBL625CVCX
The kit includes one 625 mm
bundled cable.
