Intel® Server S2600ST Product Family Configuration Guide and Spares/Accessories List
5
Table 3. Intel® Server Board S2600ST Product Family Feature Set
Server Board Features
Detail
Server Board SKU
S2600STB S2600STQ
Processor Support
• Up to two (2) Intel® Xeon® processor Scalable family
Processor UPI Links
2
Maximum Processor TDP
Up to 205W
Memory
• 16 Total DIMM slots
o Eight (8) DIMM slots per processor
o Six (6) memory channels per processor: One (1) DDR4 DIMM slot per memory channel
on four (4) channels and two (2) DDR4 DIMM slots per memory channel on two (2)
channels
o Registered DDR4 (RDIMM), Load Reduced DDR4 (LRDIMM)
• Memory data transfer rates:
o DDR4 up to 2666 MT/s (Processor SKU Dependent)
DDR4 standard voltage of 1.2V
Intel® C62x Series Chipset
Intel® C624 Chipset
Intel® C628 Chipset
Intel® Quick Assist
Technology (QAT)
NO Yes
LAN
• Dual Port RJ45 10GbE On-Board
• Optional: Riser aligned to Slot 5 with two 10Gb SFP+ connectors
On-board PCIe* NVMe
support
• Four (4) OCuLink Connectors
• Intel® VMD Support
• Intel® VROC Support– Acc. Option
• Two (2) OCuLink Connectors
• Intel® VMD Support
• Intel® VROC Support– Acc. Option
Onboard SATA Support
• 12x SATA 6Gbps ports (6Gb/s, 3 Gb/s and 1.5Gb/s transfer rates are supported)
o Two (2) single port 7-pin SATA connectors
o Two (2) M.2 connectors – SATA / PCIe*
o Two (2) 4-port Mini-SAS HD (SFF-8643) connectors
• Embedded SATA Software RAID
o Intel® Rapid Storage RAID Technology (RSTe) 5.0
o Intel® Embedded Server RAID Technology 2 (ESRT2) 1.60 with optional RAID 5 key
support
Note: ESRT2 is supported only on 8 port SATA controller
