30 Intel
®
Server Board S5000PSL
5. Locate the DIMM sockets (see Figure 9).
6. Disconnect and remove any components necessary to access the DIMM sockets.
See the documentation that came with your chassis for instructions on removing
chassis components.
Figure 9. Locating DIMM Sockets
Callout DIMM Socket Callout DIMM Socket
A. DIMM_A1 E. DIMM_C1
B. DIMM_A2 F. DIMM_C2
C. DIMM_B1 G. DIMM_D1
D. DIMM_B2 H. DIMM_D2
AF000093
A
B
C
D E
F
G
H
