Intel S5000PSL - Server Board Motherboard - Figure 20. Removing Processor from Socket; Figure 21. Installing Protective Cover Onto Load Plate

42 Intel
®
Server Board S5000PSL
12. Lift the processor from the socket. See Figure 15.
Caution: Do not touch the contacts on either the processor or the processor socket.
Figure 20. Removing Processor from Socket
13. Store the processor in the packaging materials in which it came.
14. Install the protective cover over the load plate if a replacement processor will not be
installed.
Figure 21. Installing Protective Cover onto Load Plate
AF000416
AF000417
