10 Intel
®
Server Board S5000PSL
Callout LED Function
A. Bit 3 LED POST LED. The sequence of lit POST LEDs is used
to identify specific errors that might occur during the
boot process. See the appendix of the Technical
Product Specification for a description of how to read
these LEDs.
B. LSB LED POST LED. The sequence of lit POST LEDs is used
to identify specific errors that might occur during the
boot process. See the appendix of the Technical
Product Specification for a description of how to read
these LEDs.
C. Bit 2 LED POST LED. The sequence of lit POST LEDs is used
to identify specific errors that might occur during the
boot process. See the appendix of the Technical
Product Specification for a description of how to read
these LEDs.
D. MSB LED POST LED. The sequence of lit POST LEDs is used
to identify specific errors that might occur during the
boot process. See the appendix of the Technical
Product Specification for a description of how to read
these LEDs.
E. Status LED The status LED indicates whether a system is
operating correctly, has experienced a minor fault, or
a major system error. For details about this LED, see
the Technical Product Specification.
F. ID LED This LED can be turned on and off either by pressing
a chassis button or by using system management
software. This LED is useful when the system is
grouped with several systems, such as in a rack, and
you need to easily find the system to perform
maintenance on it.
G. System fan 6 fault LED This LED indicates a fault has occurred with system
fan 6. See your server chassis documentation for
instructions to replace the fan.
H. System fan 5 fault LED This LED indicates a fault has occurred with system
fan 5. See your server chassis documentation for
instructions to replace the fan.
I. DIMM A1 fault LED This LED indicates a fault has occurred with the
FBDIMM installed in socket DIMM_A1. Replace the
faulty FBDIMM.
J. DIMM A2 fault LED This LED indicates a fault has occurred with the
FBDIMM installed in socket DIMM_A2. Replace the
faulty FBDIMM.
K. DIMM B1 fault LED This LED indicates a fault has occurred with the
FBDIMM installed in socket DIMM_B1. Replace the
faulty FBDIMM.
