Server Board S5000PSL 11
L. DIMM B2 fault LED This LED indicates a fault has occurred with the
FBDIMM installed in socket DIMM_B2. Replace the
faulty FBDIMM.
M. DIMM C1 fault LED This LED indicates a fault has occurred with the
FBDIMM installed in socket DIMM_C1. Replace the
faulty FBDIMM.
N. DIMM C2 fault LED This LED indicates a fault has occurred with the
FBDIMM installed in socket DIMM_C2. Replace the
faulty FBDIMM.
O. DIMM D1 fault LED This LED indicates a fault has occurred with the
FBDIMM installed in socket DIMM_D1. Replace the
faulty FBDIMM.
P. DIMM D2 fault LED This LED indicates a fault has occurred with the
FBDIMM installed in socket DIMM_D2. Replace the
faulty FBDIMM.
Q. +5-volt standby LED This LED is green whenever AC power is applied to
the system. The system does not need to be
powered on in order for this LED to be on.
R. Processor 2 fault LED This LED indicates a fault has occurred with the
processor installed in socket CPU_2 socket. Replace
the faulty processor.
S. Processor 1 fault LED This LED indicates a fault has occurred with the
processor installed in socket CPU_1 socket. Replace
the faulty processor.
T. Processor 2 fan fault LED This LED applies only to server systems that use an
active heatsink. This LED indicates a fault has
occurred with fan that is installed on the heatsink for
processor 2. Replace the faulty unit.
U. Processor 1 fan fault LED This LED applies only to server systems that use an
active heatsink. This LED indicates a fault has
occurred with fan that is installed on the heatsink for
processor 1. Replace the faulty unit.
Callout LED Function
