13
Zone operation mode
Enter + 0 + M + T + Enter + select zone + Enter
M = operation mode from 5 to 8
5 = smart
6 = fast
7 = silent
8 = normally open contact
T = group of zones from 0 to 7
» Stay (as of version 5.0)
The zones selected for this option remain inactive during activation in Stay mode
regardless of the partition associated with it.
Note.: during full activation of the partition, outside of Stay mode, all zones in the
partition will trigger.
The Stay Zone function can be programmed as shown in the following table:
Enter + 38 + G + Enter
G = 0 Zones 1 to 8
1 9 to 16
2 17 to 24
3 25 to 32
4 33 to 40
5 41 to 48
6 49 to 54
7 55 to 64
» Wireless Tamper (of version 5.0)
Zones must be congured to identify Tamper and wireless sensors must have tamper.
The moment the sensor is opened, the zone will be open and a Tamper event will be
generated. The zone will remain open until the sensor closes.
