4. Installation
» To guarantee the sealing of the product, screw the lid close to the base, until you feel a good grip
and add another ¼ of rotation.
» Check the table below to select the minimum diameter of the wire to be used, according to the
installed perimeter:
3.000 m 5.000 m 6.000 m 7.000 m
High Power
ELC 5002 / ELC 5112
0,6 mm 1,2 mm x x
High Power
ELC 5003
0,6 mm 0,6 mm 0,9 mm 1,2 mm
» The product and its auxiliary equipment must be installed, operated and maintained in a way to
minimize the danger to people, reducing the risk of electric shock; unless someone tries to cross the
physical barrier or is in the protected area without authorization.
» The construction of electric security fences where the accidental entrapment or entanglement of indi-
viduals is likely should be avoided.
» Gates with electric security fences must be able to open without the user receiving an electric shock.
» An electric security fence must not be powered by two separate electriers.
» For any two separate electric safety fences, each powered by a separate, independently timed electri-
er, the distance between the wires of these two electric safety fences must be at least 2.5 m. If this
space is protected, this protection must be carried out by means of an electrically non-conductive
material or an insulated metal barrier.
» Barbed or sharp wires must not be electried by the product.
» The recommendations regarding grounding contained in this manual must be followed.
» The distance between any earth electrode of an electric security fence and other earthing systems
must not be less than 2 m, except when associated with an earthing mesh.
» Whenever possible, the distance between any electrical grounding electrode of the security fence and
other grounding systems should be at least 10 m.
» Exposed conductive parts of the physical barrier must be efciently grounded.
» When the electric fence passes below uninsulated power line conductors, its highest metallic element
must be efciently grounded for a distance of not less than 5 m to either side of the crossing point.
» High voltage conductors installed inside buildings must be efciently insulated from the grounded
structural parts of the building. This can be achieved using a high voltage insulating cable.
» High voltage conductors installed below ground must be placed inside conduits/ducts made of insu-
lating material or an insulating high voltage cable must be used. Damage to high voltage conductors
due to vehicle wheels when pressing on the ground must be avoided.
» High voltage conductors must not be installed in the same conduit/duct as mains wiring, signal cables,
audio, video and others.
» High voltage conductors and electric security fence wires must not run over overhead power lines
and/or communication lines.
