7. Operation
7.1. Activation/deactivation of the fence/alarm
Press the previously programmed remote control key. The siren will beep and the fence will be activated.
The drive does not have a time delay, therefore, all modules must be closed and the fence must be in
good condition. To deactivate the fence, trigger the remote control again. The siren will beep twice and
the fence will be deactivated.
Note: the siren will only beep if the key is activated.
7.2. LEDs
LEDs Status Description
Activated
Wiped out Fence and alarm off
On Fence or alarm activated
Fast blinking perimeter learning
Fence
Wiped out Disabled fence
Flashing 1/1 second Fence activated
Fast blinking There was a re in the fence
Slow blinking Electrier failure
Zone
Wiped out Alarm off
On¹ Alarm activated
Fast blinking There was a trigger on the alarm
Battery/network
On Mains and active battery
Flashing quickly No battery or dead battery
Blinking slowly Lack of AC network
Flashing slow and fast Lack of AC power and dead battery
¹ When the fence function is disabled and the zone is open the LED will remain lit.
7.3. Electrier operation
The fence generates a high voltage pulse every one second, monitoring the cut and ground.
If the return pulse is different from the one memorized in learning, the fence considers it as a faulty
pulse. When N failed pulses occur in a row, the fence triggers the alarm.
Note: N = programmed fault pulse amount.
The amount of fault pulse is programmable: minimum 5 and maximum 36 pulses.
