18
» Connect the battery cable to connector J6 on the board.
Battery positive pole
Battery negative pole
Black thread
Red thread
6. Close and screw the lid when nished.
Attention: when the control unit is initially powered only by battery, check the procedure for the item
Starting with battery.
If you do, the control panel will generate 4 beeps on the siren, indicating an error. This happens when
the fence is turned on for the rst time or after there is no power at all.
