Installation Guide 37
4. Route the cables through the sealing plugs in the back
box.
a) Pierce the sealing plugs on the back box.
b) Thread cables through the sealing plugs.
Note:
• For RJ45 network interface, use the supplied cable
routing tool.
• For the audio interface, first thread the audio cable
through the sealing plug and then connect the audio
connector to the cable.
