Interlogix TruVision 6 Series User Manual

74 Installation Guide
Operating temperature
-30 to +60 °C (-22 to 140°F)
Dimensions
111 × 82.4 mm
(4.4 × 3.2 in.)
Weight
500 g (1.1 lbs.)
Environmental rating
IP67, IK10
TruVision IP motorized lens dome
cameras
Electrical
Voltage input
12 VDC, PoE (IEEE 802.3af)
Power consumption
2MPX: Max. 12W
4MPX: Max. 11.5W
8MPX: Max. 12W
Miscellaneous
Connectors
Network Port(PoE), Audio In/Out,
Alarm In/Out, 12 VDC Power Port
Operating temperature
-30 to +60 °C (-22 to 140°F)
Dimensions
153.4 × 133.1 mm
(6.0 × 5.2 in.)
Weight
1.33 kg (2.9 lbs.)
Environmental rating
IP67, IK10

Interlogix TruVision 6 Series Specifications

General

Brand	Interlogix
Model	TruVision 6 Series
Category	IP Camera
Language	English
