Interlogix TruVision 6 Series User Manual

Installation Guide 73
TruVision IP motorized lens turret dome
Electrical
Voltage input
12 VDC, PoE (IEEE 802.3af),
Audio
In/Out, Alarm In/Out
Power consumption
2MPX: Max. 12.5 W
4MPX: Max. 12.5 W
8MPX: Max. 12.5 W
Miscellaneous
Connectors
12 VDC Power Input, Network Port
(PoE)
Operating temperature
-30 to +60 °C (-22 to +140 °F)
Dimensions
135.8 × 145.5 mm
(5.4 × 5.7 in.)
Weight
1.2 kg (2.6 lbs.)
Environmental rating
IP67, IK10
TruVision IP fixed lens dome cameras
Electrical
Voltage input
12 VDC, PoE (IEEE 802.3af)
Power consumption
2MPX: Max. 7.5W
4MPX: Max. 7.5W
8MPX: Max. 9W
Miscellaneous
Connectors
Network Port(PoE), Audio In/Out,
Alarm In/Out, 12 VDC Power Port
