Interlogix TruVision 6 Series User Manual

72 Installation Guide
Miscellaneous
Connectors
12 VDC Power Input, Network Port
(PoE+), Audio In/Out, Alarm In/Out,
Operating temperature
-30 to +60 °C (-22 to +140°F)
Dimensions
144.13 × 332.73 mm
(5.7 x 13.1 in.)
Weight
1.74 kg (3.8 lbs.)
Environmental rating
IP67, IK10
TruVision IP fixed lens turret dome
Electrical
Voltage input
12 VDC, PoE (IEEE 802.3af)
Power consumption
2MPX: Max. 7.5 W
4MPX: Max. 7.5 W
8MPX: Max. 8 W
Miscellaneous
Connectors
12 VDC Power Input, Network Port
(PoE)
Operating temperature
-30 to +60 °C (-22 to +140 °F)
Dimensions
127.3 × 95.9 mm
(5.01 × 3.78 in.)
Weight
620 g (1.37 lbs.)
Environmental rating
IP67

Interlogix TruVision 6 Series Specifications

General

Brand	Interlogix
Model	TruVision 6 Series
Category	IP Camera
Language	English
