Interlogix TruVision DVR 15HD - Appendix A Specifications

TruVision DVR 15HD User Manual 147
Appendix A
Specifications
TVR 150c4HD TVR 1508HD TVR 1516HD
Video
& audio input
Video compression
H.264
V
ideo input 4-ch,
BNC interface (1.0 Vp-
p,
75 Ω), supporting
coaxitron connection
8-ch,
BNC interface (1.0 Vp-
p, 75 Ω), supporting
coaxitron connection
16-ch,
BNC interface (1.0 Vp-p,
75 Ω), supporting
coaxitron connection
Supported HDTVI input
1080p/25Hz, 1080p/30Hz, 720p/25Hz, 720p/30Hz, 720P/50Hz, 720p/60Hz,
3MP, 5MP
BNC input
Supported
IP video input
Up to 4-ch (Disabled all
analog cameras)
Up to 8-ch (Disabled all
analog cameras)
Up to 16-ch (Disabled all
analog cameras)
Audio compression
G711u
Audio input
4-ch, RCA (2.0 Vp-p, 1 kΩ)
Video & a
udio output
BNC output
Support (Only for aux output)
HDMI
/VGA output VGA: 1-ch, 1920 × 1080/60Hz, 1280 ×
1024/60Hz, 1280 × 720/60Hz, 1024 ×
768/60 Hz
HDMI: 1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024
× 768/60 Hz
Encoding resolution
5MP@12 fps / 3MP@15 fps / 1080p / 720p / WD1 / 4CIF / VGA/CIF
Frame rate
Main stream: 25 fps (PAL) / 30 fps (NTSC)
Substream: WD1/4 CIF@12 fps (non-real time); CIF / QVGA / QCIF (real
time)
Video bit rate
32 Kbps to 10 Mbps
Analog output
1-ch, BNC (1.0 Vp-p, 75 Ω),
Resolution: PAL: 704 × 576; NTSC: 704 × 480
Audio output
1-ch, RCA (Linear, 1 KΩ)
Audio
bit rate 64 Kbps
Stream type
Video, Video & Audio
