Chapter 5: Live view
TruVision DVR 15HD User Manual 27
The system status is displayed on the front panel by the status LEDs.
Video output
The TVR 15HD has one HDMI and one VGA port.
The recorder automatically checks the monitor outputs used on startup. HDMI and VGA
monitors will always be the main monitor; they will both show the same view. Monitor A
is main monitor.
The event monitor (always BNC) is used to display detected events such as motion.
Only one monitor can be controlled at a time.
Live view mouse menu
Many features of live view can be quickly accessed by placing the cursor on a live
image and clicking the right-button of the mouse. The mouse menu appears (see
Figure 14 below).
Figure 7: The mouse menu for monitor A (main monitor)
The list of commands available depends on which monitor is active; main or auxiliary
(monitor B). See Table 6 on page 28. The default settings of these commands are
provided in the appendix under āDefault menu settingsā on page 156.
