Intermec 3400

HelvC
NugFont
Code39
Specifications
A-5
A
Media
G
3XXXU.O55
D
C
A
B
E
F
H
Number Description Minimum Maximum
A Label width 0.65 inch (16.5 mm) 4.4 inches (111.8 mm)
B Backing width (or tag width) 0.75 inch (19.1 mm) 4.5 inches (114.3 mm)
C Gap between labels 0.125 inch (3.2 mm) 0.5 inch (12.7 mm)
D Label length - self-strip media
Label length - butt cut media
1.0 inch (25.4 mm)
0.5 inch (12.7 mm)
Not limited
Not limited
E Media thickness (including backing) 0.0059 inch (0.15 mm) 0.0100 inch (0.25 mm)
F Reflective sensor mark length 0.5 inch (12.7 mm) N/A
G Notch radius 0.06 inch (1.52 mm) 0.125 inch (3.18 mm)
H Notch height 0.25 inch (6.4 mm) N/A
Roll diameter 8.38 inches (213 mm)
Memory (3400C only)
Base 512K of DRAM
128K of SRAM, 60K default allocated for storage
Optional 512K of SRAM
2, 6, or 8 MB flash module
