Adjusting the Label Mark Sensor
The label mark sensor detects the mark on the back of continuous media stock.
The printer uses the output to determine the start of print. The label mark
sensor is behind the platen roller and near the inboard edge of the printer.
To adjust the label mark sensor
1. Remove the media cover and locate the label mark sensor.
2. Use your index finger to slide the label mark sensor to the correct position
for your media. You can position the label mark sensor anywhere from the
inboard edge of the printer to the center of the paper path.
3. Enable mark printing with PrintSet, your third-party software, or IPL
commands. For help, see PrintSet online help, your third-party
documentation, or the
IPL Programming Reference Manual
.
4. Print a few labels or press Feed/Pause two times to make sure that the label
mark sensor is detecting the black mark on the media.
5. Replace the media cover.
