Intermec 3400

HelvC
NugFont
Code39
Specifications
A-9
A
Media
G
3XXXU.O55
D
C
A
B
E
F
H
Number Description Minimum Maximum
A Label width 3.0 inches (76.2 mm) 6.6 inches (167.6 mm)
B Backing width (or tag width) 3.1 inches (78.7 mm) 6.7 inches (170.2 mm)
C Gap between labels 0.125 inch (3.2 mm) 0.5 inch (12.7 mm)
D Label length - self-strip media
Label length - butt cut media
0.5 inch (12.7 mm)
0.5 inch (12.7 mm)
Not limited
Not limited
E Media thickness (including backing) 0.0059 inch (0.15 mm) 0.010 inch (0.25 mm)
F Reflective sensor mark length 0.5 inch (12.7 mm) N/A
G Notch radius 0.06 inch (1.52 mm) 0.125 inch (3.18 mm)
H Notch height 0.25 inch (6.4 mm) N/A
Roll diameter 8.38 inches (212.9 mm)
Memory
Base 512K of DRAM
128K of SRAM standard, 60K default allocated for storage
Optional 512K of SRAM expanded
