Intermec 3400

3400, 3440, and 3600 Bar Code Label Printer User’s Manual
HelvC
** 1233*
FG 8pt Italic
1-8
Loading Media for Fanfold Printing
3XXXU.006
Media access
slot
Fanfold
media
1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8
O
I
➤
➤
➤
➤
➤
Lower
media guide
Head lift
lever
Supply
roll
post
Edge
guide
Supply
roll
retainer
11. Press Feed/Pause to advance one label through the printer and out the label
opening in the front cover. The printer is now ready to print the
configuration test label. The yellow Empty/Pause LED goes out.
Note: If the yellow Empty/Pause LED does not go out, press Feed/Pause a second time
and then reload the media and try again if the Empty/Pause LED still does not go out.
Note: For your convenience, refer to the label with directions for loading media. This
label is located on the inside of the media cover.
