Maintaining the Printer

3-11

3

Cleaning the Label Sensors

3XXXU.036

Label gap

sensor

Label mark

sensor

Label taken

sensor

Drive

roller

Cotton

swab

Cleaning

brush

Upper media

guide

(underside)

Lower

media guide
