CK71 Service Work Instructions
CK71A
SWICK71-000
Page 40 of 42
OPERATION:
Labeling
The CK71 contains a variety of labels on its bottom housing. These labels consist of both pre-printed labels that are
ready to apply off the shelf and print on demand labels that have specific content that must be printed to match the
particular unit being serviced. Anytime a bottom housing assembly is replaced it will need new labels installed. See
the Service Repair Information web site for software and format files needed to reproduce the print on demand label
set.
Tools Required
Description
Part Number
Printer/Software/label format files
Isopropyl alcohol solution
Parts Required
Item
Part Number
Description
Qty
1
355-495-001
Laser warning label
1
2
819-335-001
POD Set
1
3
819-339-001
Transparent Overlay for POD set
1
4
471-004-149
Microsoft COA
1
5
E23066
WiFi MAC label
1
POD Label Set
2
1
4
5
