Intermec CV41

Appendix A — Specifications and Default Settings
CV41 Vehicle Mount Computer (Windows CE) User Guide 99
The CV41 internal power supply can accept DC input voltages in the
range of 10 to 60 VDC.
Power Supply Connector
USB Dongle Cable
Use the USB dongle cable to connect USB devices, such as a USB flash
drive to the smart dock and CV41.
Pin Signal Description
1 V In+ 10-60 nominal DC input +
2 V In+ 10-60 nominal DC input +
3 V In- Input -
4 V In- Input -
5 GND Chassis ground
6 Ignition +0 V to 60 V to start terminal
USB client
connector
USB host
connector
D9 male
connector
