Chapter 5 — Troubleshoot and Maintain the Computer
CV41 Vehicle Mount Computer (Windows CE) User Guide 83
4 Press the UPS Battery Disconnect button located below the SIM
card slot.
5 Reinstall the SIM card access panel and tighten the screws to a
torque to a value of 4-5 in/lbs.
Once power external power is reconnected to the CV41, the UPS
battery automatically reconnects.
UPS Battery
Disconnect button
