Intermec EasyCoder F4 User Manual

Intermec EasyCoder F4 – Installation & Operation Ed. 354
Chapter 7 Setting Up the Printer
Media, cont.
Setup Parameters, cont.
Direct Thermal Printing (Europe)
DT Type/ Paper Label Label Max Rec. Print Speed (mm/sec)
1
Speed Designation Constant Factor Picket Fence Bar Code
2
Ladder Bar Code
Top Coated/ Top Board
3
100 40 100 100
Standard Premium 95 40 125 125
Non Top Coated/ Economy 85 40 125 125
Standard Eco Board
3
80 40 175 175
Top Coated/High Premium High Speed 85 40 175 175
Thermal Transfer Printing (Europe)
Ribbon Receiving Ribbon Ribbon Label Max Rec. Print Speed (mm/sec)
1
Type Material Constant Factor Offset Picket Fence Bar Code
2
Ladder Bar Code
GP02 Vellum 75 25 0 150 150
Matte Coated 80 25 0 150 150
Transfer Premium 70 25 0 150 150
HP66 Matte Coated 100 25 0 200 200
Transfer Premium 85 25 0 200 200
Premium Tag
3
105 25 0 150 150
High Gloss White 95 25 0 150 150
Polyethylene Matt 75 25 0 150 150
Polyethylene Gloss 95 25 0 200 200
HP07 Matte Coated 100 25 0 150 150
Transfer Premium 95 25 0 200 200
Premium Tag
3
105 25 0 150 150
High Gloss White 110 25 0 150 150
Polyethylene Matt 90 25 0 150 150
Polyethylene Gloss 100 25 0 200 150
HP05 Matte Coated 95 25 0 150 150
Transfer Premium 80 25 0 200 200
Premium Tag
3
95 25 0 150 150
High Gloss White 80 25 0 200 200
Polyethylene Matt 75 25 0 100 100
Polyethylene Gloss 80 25 0 150 150
HR03 Polyester Gloss 100 30 0 150 150
1
/. Exceeding the recommended print speed may cause the printhead to wear out prematurely. If the ambient temperature is lower
than +15°C (+59°F), decrease print speed by 50 mm/sec.
2
/. Also applies to printing of text, images, lines, and boxes.
3
/. Requires high printhead pressure (see Chapter 13 “Adjustments, Printhead Pressure”.)
