2 EasyLAN Wireless Interface Kit Installation Instructions
Chapter 1 — Introduction
About These Instructions
ese instructions describe how to install an EasyLAN Wireless network
interface in an EasyCoder PF2i, PF4i, PF4i Compact Industrial, PM4i,
PX4i, or PX6i printer and how to connect it to a LAN, WAN, Intranet,
or Internet network via a wireless connection.
e installation instructions describe how to physically install the
interface board in a printer and how to set up the IP address, subnet
mask, default router, and name server. e instructions end when you
have the printer’s home page up and running. From there, please refer to
the Intermec EasyLAN User’s Guide on the included CD.
is interface kit must only be installed by an authorized
service technician. e device is country/region specific
and must be ordered for the correct country/region. Use of
this device in other region than shown on the device home
page/test label may violate applicable law.
Printer Firmware
e printer must be running either Intermec Fingerprint v8.40 (or later)
or IPL v2.40 (or later). In Intermec Fingerprint, the network port is
addressed as device "net1:" (communication channel #5).
Installation Kit
e EasyLAN Interface Kit contains:
• One EasyLAN adapter board complete with radio module fitted
• Rear plate (for EasyCoder PF2/4i-series printers only)
• RJ-45 plug (for EasyCoder PM4i- and PX4/6i series printers only)
• One light guide
• One hexagonal threaded spacer
• One antenna extension cable
• One antenna
• One cable clip
• One cable tie
• One CD with software and manuals
• is Installation Instruction booklet
e only tools required for the installation are #T10 and #T20 Torx
screwdrivers and a small wrench.
