EasyLAN Wireless Interface Kit Installation Instructions 31
Chapter 4 — Setup in Fingerprint
SETUP GET "8021x","STATE",A$
Gets the supplicant state: “Disabled”, “Failed”, “Authenticating”, or
“Authenticated”.
Note: If you start the printer with EAP type set to OFF and
then change the EAP type to TTLS, LEAP, or PEAP, you need
to reboot the printer for your new settings to take effect. Until
you reboot, STATE returns “Disabled.”
802.1x supplicant state, EAP type, outer name, inner authentication,
installed root certificate, server common names, and server certificate
validation can be seen on the printer's web page and the network test
label.
Reading Other Wireless Connection Variables
In addition to SSID, WEP, WLAN, and 802.1x settings, the following
information can be read using SETUP GET instructions:
• Active channel
1,3
• MAC address of the access point
1
• Signal strength
1,3
• Speed
1
• Region
2
1
/. e information is also given on the network test label and on the
web page.
2
/. e current region is also presented on the web page.
3
/. Active channel and signal strength is shown in the printer’s display
window when the <i> key is pressed.
Active Channel
802.11b/g operates on a number of different channels, corresponding
to different frequencies. e printer scans for a suitable access point and
channel. e selected channel can be read from the printer. e read-
only setup-variable “CHANNEL” can assume values from 0 up to 14
depending on the region setting. 0 signifies that an association has not
yet been made, 1-14 is the currently selected channel.
