Chapter 1 — Learning About Programming the SR60 Scanner
SR60 Scanner Programmer’s Reference Manual 7
This type of format may require up to six programming bar codes
and is necessary to allow flexible programming with larger item-
value numeric ranges.
Sample C
Programming sample C lets you scan a single, extended length
bar code. This special bar code contains all the data necessary to
enter Programming mode, set the Item Tag and Item Value, and
exit Programming mode all in one step.
Roadmap for Programming the Scanner
Follow this roadmap to program the SR60 scanner.
To program the scanner
1 Scan any feature bar codes that are unique to the interface you
are currently programming. These interface-specific
programming bar codes immediately follow each interface
selection bar code.
2 If you need to change any bar code symbologies or modify
any symbology-related features, see “Enabling Symbologies”
on page 70.
3 If you need to change or modify any other features (such as
beeper settings), see Chapter 5, “Configuring General
Features,” on page 139.
Once the necessary changes have been made, and you have
scanned the END bar code, you are ready to operate the SR60
scanner.
About the Scanner LEDs and Beeper
The scanner provides a set of indicators that verify or announce
scanner functions.
Scanner LEDs
The amber Laser On LED is located on top rear of the scanner
and lights whenever laser power is on.
Note: The green LED and beeper are configurable features which
may have been modified or disabled. For help, see Chapter 5,
“Configuring General Features,” on page 139.
