9006 Hybrid Control for RollerDrive
Setting options and wiring diagrams
This chapter explains the DIP switch settings for different application
9006 is between
two 9006 Cards
Hint
When the DIP switch settings ON / OFF are stated, both settings are possible for
the shown wiring (for the meaning of the settings see "DIP switches", page 14).
Upstream device 9006
Downstream device 9006
DIP switch 4 Off On Off On
DIP switch 5 Off On On Off
Upstream peer-to-peer jog/
reverse
Disabled Functional Disabled Functional
Downstream peer-to-peer
jog/reverse
Disabled Functional Functional Disabled
Zone type ZPA-mode ZPA-mode ZPA-mode ZPA-mode
Smart 1 (in) Jog Jog Jog Jog
Reverse (in) System
reverse
System
reverse
System
reverse
System
reverse
Smart 1 (out) Motor run Motor run Motor run Motor run
Sensor 2 Another
C sensor
Another
C sensor
Another
C sensor
Another
C sensor
